Complied of TIA-568.2-D
IEC60603-7-51
ISO/IEC11801 2.2 Edition
CENELEC EN 50173-1
PoE++ type 4
IEEE 802.3bt
IEC 60512-99-002:2019
Insulation Resistance: 500 Mohms minimum
Contact Resistance: 20 mohms maximum
Plug insertion life: 750 Cycles minimun
Plug retention force: 20 lbs minimun
Temperature: -40ºC to 68ºC
IDC-Contact: T=0.4mm phosphor bronze, Sn over nickel plating.
Accept Cable: #26~22AWG solid wire. Outer diameter 6.0~8.5
