Spectacular image quality, low maintenance and ultimate reliability
The ZU1300 offers enhanced features such as built-in edge-blending and warping as well as 4K HDR compatibility. Part of the DuraCore laser lineup, it combines a longer-lifetime light source and an independent IP-rated dust certification for ultimate peace of mind.
Delivering up to an astonishing 30,000 hours, this projector achieves superior colour rendition producing visually striking lifelike images with exceptional detail.
Designed for even the most complex professional installations, the ZU1300 offers seven interchangeable lens options including an ultra short throw lens for ultimate flexibility.
The ZU1300 offers portrait and 360-degree orientation support. Additionally, an HDBaseT™ input is included to simplify cabling requirements and reduce installation complexity, saving time and reducing costs.
Features
High brightness WUXGA DLP laser projector
14,400 lumens
DuraCore laser technology
Up to 30,000 hours laser light source
Dust resistant
Independently tested, IP6X certified for total reliability
Installation flexibility
7 interchangeable lens options including an ultra short throw lens
Display/image
| Display technology | DLP® |
| Resolution | WUXGA (1920x1200) |
| Brightness | 17,000 lumens |
| ANSI brightness | 14,500 |
| Contrast ratio | 2,000,000:1 |
| Native aspect ratio | 16:10 |
| Aspect ratio - compatible | 16:9,16:10 |
| Screen size | Dependent on lens |
Lamp info
| Light source type | DuraCore Laser |
| LASER life | 30,000 hours |
Optical
| Throw ratio | Dependent on lens |
| Projection distance (m) | Dependent on lens |
| Lens options | BX-CTA11, 0.65~0.75:1
BX-CTA18, 0.84~1.02:1
BX-CTA19, 1.02~1.36:1
BX-CTA20, 1.2~1.5:1
BX-CTA21, 1.5~2.0:1
BX-CTA22, 2.0~4.0:1
BX-CTA23, 4.0~7.2:1
BX-CTA27, 7.2~10.8:1 |
| Lens shift | Yes - see product downloads for more information |
Connectivity
| Connections | | Inputs 1 x RS232, 1 x 3D sync, 1 x Wired remote, 1 x HDBaseT, 1 x DisplayPort, 2 x HDMI 2.0, 1 x VGA, 1 x DVI-D, 1 x 3G-SDI | | Outputs 1 x RS232, 1 x 3D sync, 1 x Wired remote, 1 x HDMI 2.0, 1 x 3G-SDI | | Control 1 x RJ45, 1 x USB-A service, 1 x 12V trigger |
|
| LAN - wireless networking | No |
General
| Noise level (min) | 36dB |
| Noise level (max) | 38dB |
| 2D compatibility | HDR10/HLG |
| 3D | Full 3D |
| IP rating | IP5X |
| OSD / display languages | 11 languages: Dutch, English, French, German, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Spanish |
| 24/7 operation | Yes |
| 360° operation | Yes |
| Operating conditions | Operating: 10~85%RH, non-condensing. Storage: 5~90%RH, non-condensing |
| Remote control | Backlit ProAV remote |
Networking
| LAN - display | Yes |
| LAN - wireless networking | No |
| LAN | Yes |
Power
| Power supply | AC 100–240 V @ 50/60 Hz |
| Power consumption (standby) | 0.5W |
| Power consumption (min) | 460W |
| Power consumption (max) | 1,000W |
Weight and dimensions
| Dimensions (W x D x H) mm | 650 x 682 x 300.86 |
| Gross weight | 62.5 kg |
| Net weight | 50 kg |
