Spectacular image quality, low maintenance and ultimate reliability
The ZU1100 offers enhanced features such as built-in edge-blending and warping and 4K HDR compatibility. Part of the DuraCore laser lineup, it combines a longer-lifetime light source and an independent IP-rated dust certification for ultimate peace of mind.
Delivering up to an astonishing 30,000 hours, this projector achieves superior colour rendition producing visually striking lifelike images with exceptional detail.
Designed for even the most complex professional installations, the ZU1100 offers seven interchangeable lens options including an ultra short throw lens for ultimate flexibility.
The ZU1100 offers portrait and 360-degree orientation support. Additionally, an HDBaseT™ input is included to simplify cabling requirements and reduce installation complexity, saving time and reducing costs.
Features
High brightness WUXGA DLP laser projector
11,500 lumens
DuraCore laser technology
Up to 30,000 hours laser light source
Dust resistant
Independently tested, IP6X certified for total reliability
Installation flexibility
7 interchangeable lens options including an ultra short throw lens
Display/image
| Display technology | DLP® |
| Resolution | WUXGA (1920x1200) |
| Brightness | 11,500 lumens |
| ANSI brightness | 9,600 |
| Contrast ratio | 2,000,000:1 |
| Native aspect ratio | 16:10 |
| Aspect ratio - compatible | 4:3,16:9,16:10 |
| Keystone correction - horizontal | +/-20° |
| Keystone correction - vertical | +/-20° |
| Uniformity | 90% |
| Screen size | Dependent on lens |
Lamp info
| Light source type | Laser |
| LASER life | 30,000 hours |
Optical
| Throw ratio | Dependent on lens |
| Projection distance (m) | Dependent on lens |
| Lens options | BX-CTA16- 0.36 ~ 0.36
BX-CTA17- 0.65~0.75
BX-CTA15- 0.75 ~ 0.95
BX-CTA01- 0.95 ~ 1.22
BX-CTA06- 1.22 ~ 1.52
BX-CTA03- 1.52 ~ 2.92
BX-CTA13- 2.90 ~ 5.50
|
| Lens shift | Yes - see product downloads for more information |
Connectivity
| Connections | | Inputs 2 x HDMI 2.0, 1 x 3D sync, 1 x DVI-D, 1 x HDBaseT, 1 x 3G-SDI, 1 x 12V trigger | | Outputs 1 x 3D sync, 1 x HDMI, 1 x USB-A power 2A | | Control 1 x RS232, 1 x Wired remote, 1 x RJ45 |
|
General
| Noise level (min) | 38dB |
| Noise level (max) | 40dB |
| PC compatibility | HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| 2D compatibility | PAL (625/576i/p), SECAM, NTSC (525/480i/p), HDTV (720p, 1080i/1080p) |
| 3D compatibility | Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60 |
| 3D | Full 3D |
| Security | Security bar, Kensington Lock |
| IP rating | IP6X |
| OSD / display languages | 15 languages: Dutch, English, French, German, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Chinese (simplified), Spanish, Chinese (traditional) |
| 24/7 operation | Yes |
| 360° operation | Yes |
| Operating conditions | 5°C~40°C/41°F~104°F, max altitude M/0ft, max humidity 10-85% |
| Remote control | Wired ProAV remote |
| In the box | AAA Battery, AC power cable 3M, Lens cover, Quick start guide |
| Optional wireless models | QuickCast Bundle, QuickCast starter kit |
Networking
Power
| Power supply | 100 - 240V, 50 - 60Hz |
| Power consumption (standby) | 0.5W |
| Power consumption (min) | 360W |
| Power consumption (max) | 680W |
Weight and dimensions
| Dimensions (W x D x H) mm | 484 x 529 x 207.8 |
| Gross weight | 27 kg |
| Net weight | 21 kg |
