Bright Short Throw Projector
Bright short throw professional laser projector
Spectacular image quality, low maintenance and ultimate reliability
At 5000 lumens, with 4K and HDR compatibility, the ZU507TST combines a long-lifetime light source of up to 30,000 hours and an independent IP6X certified optical engine for 24/7 operation, offering truly maintenance-free projection.
Added features include:
- Short throw lens
- Manual horizontal and vertical lens shift
- Built-in 10W speakers
Suitable for a wide variety of applications, this bright, short throw projector is perfect for immersive spaces and simulation applications. Golf sim picture mode delivers true-to-life greens and blues and impressive detailing even with the lights on.
The added control flexibility of HDBaseT and LAN make this projector an affordable set-and-forget solution.
Eco-Friendly Design
Designed with the environment in mind, this projector features:
- Eco-friendly chassis design made with up to 50% PCR (Post-Consumer Recycled) plastics
- Packaging contains up to 97% recyclable materials
Projector Specifications
Specification
Display / Image
| Display technology | DLP® |
|---|
| Resolution | WUXGA (1920x1200) |
|---|
| Brightness | 5,000 lumens |
|---|
| Contrast ratio | 300,000:1 |
|---|
| Native aspect ratio | 16:10 |
|---|
| Aspect ratio - compatible | 4:3, 16:9, 16:10 |
|---|
| Keystone correction - horizontal | ±15° |
|---|
| Keystone correction - vertical | ±15° |
|---|
| Vertical auto keystone correction | Yes |
|---|
| Displayable colours | 1073.4 million |
|---|
| Horizontal scan rate | 5~140KHz |
|---|
| Vertical scan rate | 24~120Hz |
|---|
| Uniformity | 85% |
|---|
| Screen size | 0.76m ~ 7.62m (30" ~ 300") diagonal |
|---|
Lamp Info
| Light source type | DuraCore Laser |
|---|
| Laser life | 30,000 hours |
|---|
Optical
| Throw ratio | 0.58:1 |
|---|
| Projection distance | 0.38m - 3.75m |
|---|
| Zoom type | Fixed |
|---|
| Focal length | 8.51 mm |
|---|
| Lens shift | Vertical -100 ~ 110%, Horizontal: ±4% |
|---|
| Native offset | 100% |
|---|
| Lens shift available | Yes - see product downloads for more information |
|---|
Connectivity
| Inputs | 2 x HDMI 2.0, 1 x VGA, 1 x Composite video, 2 x Audio 3.5mm |
|---|
| Outputs | 1 x USB-A power 1.5A, 1 x Audio 3.5mm, 1 x VGA |
|---|
| Control | 1 x 12V trigger, 1 x HDBaseT, 1 x RJ45, 1 x RS232 |
|---|
| LAN - wireless networking | No |
|---|
General
| Noise level (min) | 33dB |
|---|
| Noise level (max) | 36dB |
|---|
| 3D | Full 3D |
|---|
| Security | Security bar, Kensington Lock, Password protected interface |
|---|
| IP rating | IP6X |
|---|
| OSD / display languages | 25 languages including English, Norwegian, Japanese, etc. |
|---|
| 360° operation | Yes |
|---|
| Remote control | Backlit ProAV remote |
|---|
| Speaker count | 2 |
|---|
| Watts per speaker | 10W |
|---|
| In the box | AC power cord, Remote control, 2x AAA batteries, Basic user manual |
|---|
Networking
| LAN - control | Yes |
|---|
| LAN - wireless networking | No |
|---|
| LAN | Yes |
|---|
Power
| Power supply | Universal AC 100--240V± 10%~ 50 / 60 Hz with PFC input |
|---|
| Power consumption (standby) | <0.5W |
|---|
| Power consumption (min) | 240W |
|---|
| Power consumption (max) | 366W |
|---|
Weight and Dimensions
| Dimensions (W x D x H) | 374 x 302 x 117 mm |
|---|
| Gross weight | 7.3 kg |
|---|
| Net weight | 5.3 kg |
|---|
