Philips D-Line 86” HD, 24/7, 600 nits

86BDL5050D/00 , Failover , Android 14

Varenr: 137909
Alt. varenr: 86BDL5050D/00
BeskrivelseEkstern InfoTeknisk info
Beskrivelse

86BDL5050D/00

Energy Label: f

5000 Series / D-Line

Go beyond the ordinary. Captivate audiences and elevate their experience with the Philips Signage 5000. Powered by Android 14 for smooth integrations, this versatile 24/7 display steps up to deliver exceptional performance in any setting.



ConnectivityToggle
Audio output3.5 mm jack
Other connections4G/LTE antenna connectors, Micro USB (x 1) (OTG), USB 3.0 (x 2),
External controlRJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack, Wi-Fi 6, Bluetooth 5.2 (via CRD32),
Video outputHDMI 2.0
Video inputDisplayPort 1.4 (x 1), HDMI 2.0 (x 2), USB-C (4.5 W),
ConvenienceToggle
Tiled MatrixUp to 10 x 15
Network controllableRS232, External 4G mPCIe slot, RJ45,
Signal loop throughRS232, IR Loop through, HDMI1, HDMI 2, Android SoC,
Keyboard controlHidden, Lockable,
Screen-saving functionsPixel Shift
PlacementLandscape (24/7), Portrait (24/7),
Energy-saving functionsSmart Power
AccessoriesToggle
Included AccessoriesRS232 daisy-chain cable, Philips logo (x 1), AC Switch Cover, USB Cover (x 1), Screws, AC Power Cord, IR sensor cable (1.8 m) (x 1), Quick start guide, Remote control and AAA batteries, RS232 cable, CRD32 Wi-Fi and BT module,
Internal PlayerToggle
GPUARM Mali G52 MC3
CPU4 x A72 + 4 x A53 RK3576 + MT9800
Storage32 GB
Memory4 GB RAM
DimensionsToggle
Wall Mount600 (H) x 400 (V) mm, M8
Set Height1100 mm
Set Depth69.5 (D@Wall mount)/91.8 (D@Handle) mm
Set Height (inch)43.31 inch
Product weight (lb)106.51 lb
Bezel width15.5 mm (Even bezel)
Product weight48.31 kg
Set Depth (inch)2.74 (D@Wall mount) / 3.61 (D@Handle) inch
Set Width (inch)75.94 inch
Set Width1929.0 mm
SoundToggle
Built-in speakers2 x 10 W RMS
PowerToggle
ConsumptionEEI lot5 153 W
Mains power100 ~ 240 VAC, 50 ~ 60 Hz
Standby power consumption<0.5 W
Energy Label ClassF
Multimedia ApplicationsToggle
USB Playback AudioAAC, HEAAC, MPEG,
USB Playback PictureBMP, JPEG, PNG,
USB Playback VideoMPEG, H.263, H.264, H.265, AVI, MP4, MPEG4, VP8, VP9, WEBM,
Operating conditionsToggle
MTBF50,000 hour(s)
Altitude0 ~ 3000 m
Temperature range (storage)-20 ~ 60 °C
Humidity range (operation)[RH]20–80% RH (No condensation)
Humidity range (storage) [RH]5–95% RH (No condensation)
Temperature range (operation)0 ~ 40 °C
MiscellaneousToggle
On-Screen Display LanguagesEnglish, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish,
Warranty3 year warranty
Regulatory approvalsCE, RoHS, CB,
Picture/DisplayToggle
Display colours1.07 Billion
Brightness600 cd/m²
Diagonal screen size (metric)217.4 cm
Dynamic contrast ratio500,000:1
Aspect ratio16:9
Viewing angle (horizontal)178 degree
Diagonal screen size (inch)85.6 inch
Haze25%
Response time (typical)8 ms
Panel technologyADS
Operating systemAndroid 14
Contrast ratio (typical)1200:1
Viewing angle (vertical)178 degree
Optimum resolution3840 x 2160 @ 60 Hz
Panel resolution3840 x 2160
Pixel pitch0.4935 x 0.4935 mm
Picture enhancement3/2 - 2/2 motion pull down, Motion compens. deinterlacing, Dynamic contrast enhancement, Progressive scan,
Supported Display ResolutionToggle
Computer formats1024 x 768, 60 Hz, 1280 x 1024, 60 Hz, 1280 x 720, 60 Hz, 1440 x 900, 60 Hz, 1600 x 900, 60 Hz, 1680 x 1050, 60 Hz, 1920 x 1080, 60 Hz, 640 x 480, 60 Hz, 800 x 600, 60 Hz,
Video formats1080p, 50, 60 Hz, 1080i, 50, 60 Hz, 480p, 60 Hz, 576i, 50 Hz, 576p, 50 Hz, 720p, 50,60 Hz, 480i, 60 Hz,




Ekstern Info
ProdusentDrawingManualProduct
Teknisk info

Produktinformasjon

Android Versjon Android 14
Driftstid 24/7
Haze 25%
Lysstyrke 600 nits
Modell Philips D-line
Oppløsning
  • 4K
  • 3840x2160
Skjermtype Signage
Størrelse
  • 32"
  • 86"
