Product information:
The BLS Series consists of double-isolated loudspeaker cables
with twisted conductors and a smooth,
flexible PVC outer
jacket. Designed for use in public address (100V) audio systems,
their durable construction ensures convenient
installation and
reliable long-term performance.
Built with stranded copper clad aluminum (CCA), these cables
combine the lower weight and material cost of aluminum with
the improved conductivity and solderability of copper.
Now rated with a CPR Euroclass Eca classification, the BLS
Series meets basic fire safety requirements for fixed
installations.
Always consult local regulations to confirm where
Eca class cables are permitted.
More information about CPR compliant cables? Click here
Highlights:
• 13 AWG (2.5 mm²) thin and dense stranded conductors
• EN60332-1-2 CPR Euroclass Eca
• Double isolated
• Smooth & durable outer jacket
• Oxygen free copper conductors
• Meters indication marking
Specifications
Physical characteristics
| Inner conductor | Insulation | Material | PVC 3.8 mm (Ø) |
| | Colours | Red / Blue |
| Outer jacket | Material | Flexible PVC 9.8 mm (Ø) |
| Colours | Black |
| | White |
| Inner conductor | Material | CCA 49 x 0.25 mm (Ø) |
| Section | 2.5 mm² |
| American Wire Gauge | 13 AWG |
| Number of conductors | 2 |
Standards and regulations
| RoHS2 compliant | According EU Directive 2011/65/EU |
| Reach compliant | According EC 1907/2006 |
| Indoor / outdoor | Indoor |
| CPR Euroclass | Eca |
| Flammability test | According EN 60332-1-2 |
Mechanical characteristics
| Temperature range | Fixed installation | - 15 °C till + 80 °C |
| Mobile installation | - 5 °C till + 80 °C |
Electrical characteristics
| Max. conductor | DC resistance | 1.1 ? / 100 m |
| Dielectric strength | 1200 V/min |
| Rated voltage | 300 V |
