BrandSONANCE
Product CategoryInvisible Series
TypeSpeaker
Speaker AestheticInvisible
Speaker SizeMedium
ColorWhite
WarrantyLIMITED FIFTEEN (15) YEAR
Power Handling160 watts RMS
Air Flex Woofer191in^2 (1234cm^2) air pulse diaphragm, 8in (203mm) carbon fiber woofer
Dimensions No Feet (WxHxD)16.1" x 24.13" x 3.86" (408.94 mm x 612.9 mm x 98.04 mm)
Dispersion Technology170 degree hemispherical up to 10kHz
Frequency Response (+/- 3dB)40Hz - 30kHz
Installation LocationIn-Wall In-Ceiling
Mounting Depth - Speaker Only3.39" (86.11 mm)
Nominal Impedance4 Ohms
Product Depth3.86" (98.04 mm)
Product Dimensions (WxHxD)16.1" x 24.13" x 3.86" (408.94 mm x 612.9 mm x 98.04 mm)
Product Height24.13" (612.9 mm)
Product Height (No Feet)24.13" (612.9 mm)
Product Weight25.24 lbs. (11.45 kg)
Product Width16.1" (408.94 mm)
Sensitivity86dB (2.83V/1m)
Shipping Dimensions WxHxD19.88" x 7.68" x 26.97" (504.95 mm x 195.07 mm x 685.04 mm)
Shipping Weight31.97 lbs. (14.5 kg)
Transformer Taps70 V / 100 V: 60W, 30W and 15W
70 V: 7.5W
Wave Flex Drive Unit29in^2 (188cm^2) bending wave diaphragm, 1.75in (44mm) voice coil
