BrandSONANCE
Product CategoryOmni Series
TypeSpeaker
ColorBrown
WarrantyLIMITED FIVE (5) YEAR
Power Handling120W Continuous Program Power, 60 W Continuous Pink Noise
Crossover Point500Hz
Directivity Factor (Q)2.3
Directivity Index (DI)3.6
Frequency Response (+/- 10dB)38Hz - 25khz
Frequency Response (+/- 3dB)60Hz - 40kHz
HF DriverFour x 1.25†(32mm) Wide-Band Drivers
HiZ/LoZ70V/100V, 8 Ohm
Impedance8 ohms nominal; 6 ohms minimum
Input ConnectorFlying Leads
Installation LocationOutdoor Above Ground
IP RatingIP66
LF Driver6.5" (165mm) Polypropylene Cone, Santoprene Rubber Surround
Nominal Coverage Angle360 degrees horizontal, 160 degrees vertical
Operating HumidityConforms to Mil Spec 810 for humidity
Product Diameter12" (304.8 mm)
Product Height14.5" (368.3 mm)
Product Height (No Feet)14.5" (368.3 mm)
Product Width12" (304.8 mm)
Rated Maximum SPL107dB @ 1 meter (3.3 feet) average, 113dB peak
Sensitivity88dB (2.83V/1m)
Shipping Dimensions WxHxD14.37" x 16.73" x 14.37" (365.0 mm x 425.0 mm x 365.0 mm)
Shipping Weight19.25 lbs. (8.73 kg)
Transformer Taps70 V / 100 V: 80W, 40W, 20W
70 V: 10W
