BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRound
Speaker Size8"
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling300W program, 150W pink noise
Crossover Point150Hz
Cut-Out Dimensions (Diameter)10.125" (257.18 mm)
Frequency Response (+/- 10dB)32Hz – 300Hz
Frequency Response (+/- 3dB) 50Hz – 150Hz
Grille MaterialOne Piece Paintable Grille with Magnetic Retention
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFour pin, Euroblock with loop output connections
Installation LocationIn-Ceiling
KnockoutsOne, Side mounted 0.75" (19mm)
LF Driver8" (203mm) Polypropylene Cone, Butyl Rubber Surround
Maximum Mounting Surface Thickness1.732" (44mm)
Maximum Operating Temperature140 F (59.9 C)
Minimum Impedance6 Ohms
Minimum Operating Temperature-4 F (-19.98 C)
Nominal Impedance8 Ohms
Product Depth9.84" (249.94 mm)
Product Diameter11.06" (280.92 mm)
Product Dimensions - Square Trimless Grille (WxH)11.14" x 11.14" (283mm x 283mm)
Product Dimensions - Trimless Grille (WxH)11.06" (281mm)
Product Dimensions (Diameter x D)11.06" x 9.84" (280.92 mm x 249.94 mm)
Product Weight14.95 lbs. (6.78 kg)
Rated Maximum SPL110dB @ 1 meter (3.3 feet, 116dB peak
Sensitivity89dB (2.83V/1m)
Shipping Dimensions WxHxD14.7" x 17.2" x 27.1" (373.38 mm x 436.88 mm x 688.34 mm)
Shipping Weight25.5 lbs. (11.57 kg)
Suspension PointsOne, on top surface
Transformer Taps70 V / 100 V: 120W, 60W and 30W
70 V: 15W
