BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRound
Speaker Size8"
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling300 watts program, 150 watts pink noise
Crossover Point150Hz
Frequency Response (+/- 10dB)32Hz – 300Hz
Frequency Response (+/- 3dB)50Hz - 150Hz
Grille Diameter11.06" (280.92 mm)
Grille MaterialBezel-less magnetically retained grille
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFour pin Euroblock with loop output connections
Installation LocationPendant
LF Driver8" (203mm) Polypropylene Cone, Butyl Rubber Surround
Minimum Impedance6 Ohms
Nominal Impedance8 Ohms
Product Depth19.7" (500.38 mm)
Product Diameter11.06" (280.92 mm)
Product Dimensions (Diameter x D)11.06" x 19.7" (280.92 mm x 500.38 mm)
Rated Maximum SPL110dB @ 1 meter (3.3 feet), 116dB peak
Sensitivity89dB
Shipping Dimensions WxHxD14.0" x 14.2" x 22.1" (355.6 mm x 360.68 mm x 561.34 mm)
Shipping Weight23.1 lbs. (10.48 kg)
Transformer Taps70 V / 100 V: 120W, 60W and 30W
70 V: 15W
