BrandSONANCE
Product CategoryProfessional Series
TypeWoofer / Subwoofer
ColorBlack
WarrantyLIMITED FIVE (5) YEAR
Power Handling500 watts program, 300 watts pink noise
Crossover Point150Hz
Frequency Response (+/- 10dB)34Hz - 155Hz
Frequency Response (+/- 3dB)44Hz - 132Hz
HiZ/LoZ70V/100V, 8 Ohm
Impedance4 Ohms nominal, 3.7 Ohms minimum
Input ConnectorFour pin, Euroblock with loop output connections
LF DriverDual 10" woven glass fiber cones Butyl rubber surrounds
Product Depth13.78" (350.01 mm)
Product Dimensions (WxHxD)33.0" x 8.98" x 13.78" (838.2 mm x 228.09 mm x 350.01 mm)
Product Height8.98" (228.09 mm)
Product Weight61 lbs. (27.67 kg)
Product Width33" (838.2 mm)
Rated Maximum SPL121dB @ 1 meter (3.3 feet), 127dB peak
Sensitivity94dB (2.83V/1m)
Shipping Dimensions WxHxD20.28" x 15.55" x 39.76" (515.11 mm x 394.97 mm x 1009.9 mm)
Shipping Weight71.65 lbs. (32.5 kg)
Suspension Points4 x M10 on two sides
Transformer Taps70 V 100V: 300W, 150W
70 V: 75W
