BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRectangle
Speaker Size4"
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling60 watts program, 30 watts pink noise
Crossover Point3000Hz
Directivity Factor (Q)7.6
Directivity Index (DI)8.1
Frequency Response (+/- 10dB)57Hz - 25kHz
Frequency Response (+/- 3dB)75Hz - 20kHz
Grille MaterialPowder Coated Aluminum Friction Fit
HF Driver1" (25mm) Cloth Dome, Ferrofluid cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFront-mounted four pin, Euroblock with loop output connections
Installation LocationSurface Mount
IP RatingIP45
LF Driver4" (100mm) Polypropylene Cone, Butyl Rubber Surround
Minimum Impedance6 Ohms
Mounting Bracket Height9.685" (246.0 mm)
Mounting Bracket TypeU-Bracket with Sonance FastMount
Mounting Bracket Width4.527" (114.99 mm)
Mounting Depth - Bracket Ceiling Mount5.886" (149.5 mm)
Mounting Depth - Bracket Wall Mount5.158" (131.01 mm)
Nominal Impedance8 Ohms
Operating HumidityConforms to MIL-STD-810 for humidity, salt spray, temperature, IEC 529
Product Depth4.8" (121.92 mm)
Product Dimensions (WxHxD)5.47" x 9.25" x 4.8" (138.94 mm x 234.95 mm x 121.92 mm)
Product Height9.25" (234.95 mm)
Product Width5.47" (138.94 mm)
Rated Maximum SPL105dB @ 1 meter (3.3 feet), 110dB peak
Sensitivity87dB
Shipping Dimensions WxHxD5.47" x 4.82" x 9.25" (138.94 mm x 122.43 mm x 234.95 mm)
Shipping Weight6.61 lbs. (3.0 kg)
Transformer Taps70 V / 100 V: 30W, 15W and 7.5W
70 V: 3.8W
