BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRectangle
Speaker Size5.25"
ColorBlack
WarrantyLIMITED FIVE (5) YEAR
Power Handling90 watts program, 45 watts pink noise
Crossover Point2750Hz
Directivity Factor (Q)7
Directivity Index (DI)8
Frequency Response (+/- 10dB)43Hz-25kHz
Frequency Response (+/- 3dB)70Hz - 20kHz
Grille MaterialPowder Coated Aluminum Friction Fit
HF Driver1" (25mm) Cloth Dome, Ferrofluid cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFront-mounted four pin, Euroblock with loop output connections
Installation LocationSurface Mount
IP RatingIP45
LF Driver5.25" (130mm) Polypropylene Cone, Butyl Rubber Surround
Minimum Impedance6 Ohms
Mounting Bracket Height10.669" (270.99 mm)
Mounting Bracket TypeU-Bracket with Sonance FastMount
Mounting Bracket Width4.527" (114.99 mm)
Mounting Depth - Bracket Ceiling Mount6.575" (167.01 mm)
Mounting Depth - Bracket Wall Mount6.181" (157.0 mm)
Nominal Impedance8 Ohms
Operating HumidityConforms to MIL-STD-810 for humidity, salt spray, temperature, IEC 529
Product Depth5.68" (144.27 mm)
Product Dimensions (WxHxD)6.36" x 10.08" x 5.68" (161.54 mm x 256.03 mm x 144.27 mm)
Product Height10.08" (256.03 mm)
Product Width6.36" (161.54 mm)
Rated Maximum SPL106dB @ 1 meter (3.3 feet), 113dB peak
Sensitivity88dB (2.83V/1m)
Shipping Dimensions WxHxD6.38" x 5.67" x 10.08" (162.05 mm x 144.02 mm x 256.03 mm)
Shipping Weight8.82 lbs. (4.0 kg)
Transformer Taps70 V / 100 V: 30W, 15W and 7.5W
70 V: 3.8W
