BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRectangle
Speaker Size6.5"
ColorBlack
WarrantyLIMITED FIVE (5) YEAR
Power Handling120 watts program, 60 watts pink noise
Crossover Point2750Hz
Directivity Factor (Q)6.5
Directivity Index (DI)7.9
Frequency Response (+/- 10dB)49Hz-25kHz
Frequency Response (+/- 3dB)65Hz - 20kHz
Grille MaterialPowder Coated Aluminum Friction Fit
HF Driver1" (25mm) Cloth Dome, Ferrofluid cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFront-mounted four pin, Euroblock with loop output connections
Installation LocationSurface Mount
IP RatingIP45
LF Driver6.5" (165mm) Polypropylene Cone, Butyl Rubber Surround
Minimum Impedance6 Ohms
Mounting Bracket Height12.657" (321.49 mm)
Mounting Bracket TypeU-Bracket with Sonance FastMount
Mounting Bracket Width4.527" (114.99 mm)
Mounting Depth - Bracket Ceiling Mount8.268" (210.01 mm)
Mounting Depth - Bracket Wall Mount7.48" (189.99 mm)
Nominal Impedance8 Ohms
Operating HumidityConforms to MIL-STD-810 for humidity, salt spray, temperature, IEC 529
Product Depth6.86" (174.24 mm)
Product Dimensions (WxHxD)7.51" x 12.14" x 6.86" (190.75 mm x 308.36 mm x 174.24 mm)
Product Height12.14" (308.36 mm)
Product Width7.51" (190.75 mm)
Rated Maximum SPL108dB @ 1 meter (3.3 feet), 116dB peak
Sensitivity88dB (2.83V/1m)
Shipping Dimensions WxHxD7.52" x 6.86" x 12.15" (191.01 mm x 174.24 mm x 308.61 mm)
Shipping Weight11.46 lbs. (5.2 kg)
Transformer Taps70 V / 100 V: 60W, 30W and 15W
70 V: 7.5W
