BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRound
Speaker SizeSmall
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling60W program, 30W pink noise
Crossover Point3000Hz
Cut-Out Dimensions (Diameter)5.875" (149.23 mm)
Directivity Factor (Q)7.6
Directivity Index (DI)8.1
Frequency Response (+/- 10dB)57Hz - 25kHz
Frequency Response (+/- 3dB)75Hz - 20kHz
Grille MaterialOne Piece Paintable Grille with Magnetic Retention
HF Driver1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFour pin, Euroblock with loop output connections
Installation LocationIn-Ceiling
KnockoutsOne, Side mounted 0.75" (19mm)
LF Driver4" (100mm) Polypropylene Cone, Butyl Rubber Surround
Maximum Mounting Surface Thickness1.732" (44mm)
Maximum Operating Temperature140 F (59.9 C)
Minimum Impedance6 Ohms
Minimum Operating Temperature-4 F (-19.98 C)
Nominal Impedance8 Ohms
Product Depth7.01" (178.05 mm)
Product Diameter6.3" (160.02 mm)
Product Dimensions - Square Trimless Grille (WxH)6.36" x 6.36" (162mm x 162mm)
Product Dimensions - Trimless Grille (WxH)6.3" (160mm)
Product Dimensions (Diameter x D)6.3" x 7.01" (160.02 mm x 178.05 mm)
Product Weight5.63 lbs. (2.55 kg)
Rated Maximum SPL105dB @ 1 meter (3.3 feet), 110dB peak
Sensitivity87dB (2.83V/1m)
Shipping Dimensions WxHxD8.8" x 9.1" x 13.2" (223.52 mm x 231.14 mm x 335.28 mm)
Shipping Weight7.6 lbs. (3.45 kg)
Suspension PointsOne, on top surface
Transformer Taps70 V / 100 V: 30W, 15W and 7.5W
70 V: 3.8W
