BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRound
Speaker SizeMedium
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling120W program, 60W pink noise
Crossover Point2750Hz
Cut-Out Dimensions (Diameter)8.25" (209.55 mm)
Directivity Factor (Q)6.5
Directivity Index (DI)7.9
Frequency Response (+/- 10dB)49Hz-25kHz
Frequency Response (+/- 3dB)65Hz - 20kHz
Grille MaterialOne Piece Paintable Grille with Magnetic Retention
HF Driver1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFour pin, Euroblock with loop output connections
Installation LocationIn-Ceiling
KnockoutsOne, Side mounted 0.75" (19mm)
LF Driver6.5" (165mm) Polypropylene Cone, Butyl Rubber Surround
Maximum Mounting Surface Thickness1.732" (44mm)
Maximum Operating Temperature140 F (59.9 C)
Minimum Impedance6 Ohms
Minimum Operating Temperature-4 F (-19.98 C)
Nominal Impedance8 Ohms
Product Depth8.86" (225.04 mm)
Product Diameter9.13" (231.9 mm)
Product Dimensions - Square Trimless Grille (WxH)9.23" x 9.23" (235mm x 235mm)
Product Dimensions - Trimless Grille (WxH)9.13" (232mm)
Product Dimensions (Diameter x D)9.13" x 8.86" (231.9 mm x 225.04 mm)
Product Weight9.38 lbs. (4.25 kg)
Rated Maximum SPL108dB @ 1 meter (3.3 feet), 116dB peak
Sensitivity91dB (2.83V/1m)
Shipping Dimensions WxHxD12.2" x 12.1" x 13.2" (309.88 mm x 307.34 mm x 335.28 mm)
Shipping Weight12.0 lbs. (5.44 kg)
Suspension PointsOne, on top surface
Transformer Taps70 V / 100 V: 60W, 30W and 15W
70 V: 7.5W
