BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRound
Speaker SizeSmall
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling60W program, 30W pink noise
Crossover Point3000Hz
Cut-Out Dimensions (Diameter)5.875" (149.23 mm)
Directivity Factor (Q)7.6
Directivity Index (DI)8.1
Frequency Response (+/- 10dB)70Hz-25khz
Frequency Response (+/- 3dB)95Hz - 20kHz
HF Driver0.75" (19mm) Cloth Dome, Ferrofluid Cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFour pin, Euroblock with loop output connections
Installation LocationIn-Ceiling
KnockoutsSide mounted 0.75" (19mm)
LF Driver4" (100mm) Polypropylene Cone, Butyl Rubber Surround
Maximum Mounting Surface Thickness0.125" (3mm)
Maximum Operating Temperature140 F (59.9 C)
Minimum Impedance6 Ohms
Minimum Mounting Surface Thickness2" (50mm)
Minimum Operating Temperature-4 F (-19.98 C)
Nominal Impedance8 Ohms
Product Depth6.5" (165.1 mm)
Product Diameter6.3" (160.02 mm)
Product Dimensions - Square Trimless Grille (WxH)6.36" x 6.36" (162mm x 162mm)
Product Dimensions - Trimless Grille (WxH)6.3" (160mm)
Product Dimensions (Diameter x D)6.3" x 6.5" (160.02 mm x 165.1 mm)
Product Weight5 lbs. (2.27 kg)
Rated Maximum SPL102dB @ 1 meter (3.3 feet), 108dB peak
Sensitivity87dB (2.83V/1m)
Shipping Dimensions WxHxD10.25" x 9.75" x 14.0" (260.35 mm x 247.65 mm x 355.6 mm)
Shipping Weight6.9 lbs. (3.13 kg)
Suspension PointsOne, on top surface
Transformer Taps70 V / 100 V: 25W, 12.5W, 6.3W
70 V: 3.2W
