BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRound
Speaker SizeMedium
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling100W program, 50W pink noise
Crossover Point2750Hz
Cut-Out Dimensions (Diameter)8.25" (209.55 mm)
Directivity Factor (Q)7.8
Directivity Index (DI)8.2
Frequency Response (+/- 10dB)60Hz-25khz
Frequency Response (+/- 3dB)83Hz - 20kHz
HF Driver0.75" (19mm) Cloth Dome, Ferrofluid Cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFour pin, Euroblock with loop output connections
Installation LocationIn-Ceiling
KnockoutsOne, Side mounted 0.75" (19mm)
LF Driver6.5" (165mm) Polypropylene Cone, Butyl Rubber Surround
Maximum Mounting Surface Thickness2" (50mm)
Maximum Operating Temperature140 F (59.9 C)
Minimum Impedance6 Ohms
Minimum Mounting Surface Thickness0.125" (3mm)
Minimum Operating Temperature-4 F (-19.98 C)
Nominal Impedance8 Ohms
Product Depth8.86" (225.04 mm)
Product Diameter9.13" (231.9 mm)
Product Dimensions - Square Trimless Grille (WxH)9.23" x 9.23" (235mm x 235mm)
Product Dimensions - Trimless Grille (WxH)9.13" (232mm)
Product Dimensions (Diameter x D)9.13" x 8.86" (231.9 mm x 225.04 mm)
Product Weight6.88 lbs. (3.12 kg)
Rated Maximum SPL108dB @ 1 meter (3.3 feet), 116dB peak
Sensitivity91dB (2.83V/1m)
Shipping Dimensions WxHxD14.0" x 12.5" x 12.5" (355.6 mm x 317.5 mm x 317.5 mm)
Shipping Weight10.0 lbs. (4.54 kg)
Suspension PointsOne, on top surface
Transformer Taps70 V / 100 V: 32W, 16W and 8W
70 V: 4W
