BrandSONANCE
Product CategoryProfessional Series
TypeSpeaker
Speaker AestheticFlush / Trimless
Speaker ShapeRound
Speaker SizeMedium
ColorWhite
WarrantyLIMITED FIVE (5) YEAR
Power Handling120W program, 60W pink noise
Crossover Point2750Hz
Cut-Out Dimensions (Diameter)10.125" (257.18 mm)
Directivity Factor (Q)6.5
Directivity Index (DI)7.9
Frequency Response (+/- 10dB)49Hz-25kHz
Frequency Response (+/- 3dB)65Hz - 20kHz
Grille MaterialOne Piece Paintable Grille with Magnetic Retention
HF Driver1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled
HiZ/LoZ70V/100V, 8 Ohm
Input ConnectorFour pin, Euroblock with loop output connections
Installation LocationIn-Ceiling
KnockoutsOne, Side mounted 0.75" (19mm)
LF Driver6.5" (165mm) Polypropylene Cone, Butyl Rubber Surround
Maximum Mounting Surface Thickness1.732" (44mm)
Maximum Operating Temperature140 F (59.9 C)
Minimum Impedance6 Ohms
Minimum Operating Temperature-4 F (-19.98 C)
Nominal Impedance8 Ohms
Product Depth4.37" (111.0 mm)
Product Diameter11.06" (280.92 mm)
Product Dimensions - Square Trimless Grille (WxH)11.14" x 11.14" (283mm x 283mm)
Product Dimensions - Trimless Grille (WxH)11.06" (281mm)
Product Dimensions (Diameter x D)11.06" x 4.37" (280.92 mm x 111.0 mm)
Product Weight10 lbs. (4.54 kg)
Rated Maximum SPL108dB @ 1 meter (3.3 feet), 116dB peak
Sensitivity91dB (2.83V/1m)
Shipping Dimensions WxHxD13.0" x 7.0" x 13.9" (330.2 mm x 177.8 mm x 353.06 mm)
Shipping Weight11.3 lbs. (5.13 kg)
Specialty ApplicationLow Profile
Suspension PointsOne, on top surface
Transformer Taps70 V / 100 V: 60W, 30W and 15W
70 V: 7.5W
