Stoltzen Poseidon
CP100
Desk
Control Panel 10”
Dive into the next generation of touch control panels
with the CP100. Elegantly designed for modern applications, it seamlessly
merges with spaces such as automated office systems, multimedia rooms, and
smart homes. Its advanced programmable touch interface integrates with
configuration protocols, fostering an intelligent networking experience
tailored for AV/IT installations.
Powerful Processor: Driven by the i.MX ARM Cortex -A53
operating at 1.8GHz, CP100 assures swift and efficient performance.
High-Resolution Display: A crisp 1280x800 capacitive touch
screen in a sleek design with kickstand for table placement.
Versatile Ports: 1 bidirectional RS-232/485 and 1 LAN port
to offer optimal connectivity across various devices.
Universal Control: Direct control over all IP-based devices,
expanding its range of operability.
Power Options: Offers POE functionality or can be
powered independently via a DC 24V/1A source.
|
Specification
|
|
Processor
|
i.MX ARM Cortex -A53 1.8GHz
|
|
Operating System
|
Android OS
|
|
Bidirectional Ports
|
1x RS-232/485
|
|
Resolution
|
1280x800
|
|
Screen Type
|
Capacitive Touch Screen
|
|
PoE
|
Yes
|
|
IP-Based Device Control
|
Supported
|
|
Size
|
245.4mm x 164mm x 27mm
|
