The TX-35-IW-KVM is a reliable single Gang US Style HDBaseT 2.0 Transmitter that provides a practical solution for extending video and control signals. With support for 4K@60 resolution and USB 2.0 extension (150Mbps), it’s ideal for conference rooms, classrooms, and training facilities. For best performance, pair it with the RX-500. This setup delivers effective signal transmission in any professional AV environment.

Main Features

• High Definition Video: Single HDMI input extends 4K up to 35m and 1080p up to 70m.
• USB 2.0 Extension: USB Host port returns up to 150Mbps of USB traffic from receiver.
• Power over HDBaseT (PoH): Eliminates the need for separate power supply by powering from RX.
• RS-232 Passthrough: Full serial control via 3-pin Phoenix connection for integrated devices.

Technical Specifications

Audio and Video

• Inputs: 1x HDMI (Type A), 1x USB Host (Type B)
• Output: 1x HDBaseT
• Max Pixel Clock: 600MHz
• Video Resolutions (Max):
  • 1920x1080p @60Hz 16bit
  • 3840x2160p @30Hz 8bit 4:2:0
  • 3840x2160p @60Hz 8bit 4:2:0
  • 4096x2160p @60Hz 8bit 4:2:0
• Audio: PCM 2.0/5.1/7.1, Dolby TrueHD, Atmos, DTS-HD MA, DTS:X

Communication & Control

• HDMI: HDCP 2.2, EDID support
• USB: 1x USB 2.0 Type B host
• RS-232: 1x 3-pin Phoenix (Passthrough + Update)

Power

• Power Supply: 12V DC 1A (Sold Separately)
• PoH: Supported, 1-way from RX
• Max Power Consumption: 4.5W

Additional Features

• Reliable 4K/HD HDMI extension over HDBaseT from a 1-Gang US decora plate
• Supports 4K up to 35m (115ft)
• Optional local 12V DC phoenix power input
• Bidirectional RS-232 passthrough
• Automatic EDID management
• HDCP 2.2 compliant
• Front panel LEDs for HDCP and link status
• IEEE-568B standard compliance
• Compact design for easy installation

In the Box

• 1x TX-35-IW-KVM
• 1x 2-pin Phoenix Male Connector
• 1x 3-pin Phoenix Male Connector
• 1x Wall Plate Plastic Panel (1-Gang US)
• 1x USB-B to USB-A Host Cable
• 1x Quickstart Guide
