Key Features and Benefits
An advanced triple-camera system
High-quality audio pickup experience
Compatible with Microsoft's MDEP
Multi-Platform Flexibility
An advanced triple-camera system
The advanced triple-camera system achieves a 151° ultra-wide field of view, enabling capture of all attendees in Focus Rooms. At the same time, it provides high-definition portrait close-ups, capturing every detail of interaction and enhancing the meeting viewing experience for remote participants.
High-quality audio pickup experience
The Yealink MeetingBar A25 features a 5-meter voice pickup range, integrating a high-quality loudspeaker, 3-meter full-duplex technology, and an 8x MEMS microphone array, which delivers exceptional sound playback and voice pickup performance. Its built-in intelligent noise reduction technology ensures a superior audio experience for meetings.
Compatible with Microsoft's MDEP
Yealink MeetingBar A25 is compatible with Microsoft's MDEP, which enhances security and deployment experiences. This integration provides users with a more secure environment and streamlined deployment processes, ultimately enhancing the overall user experience.
Simple deployment
Yealink MeetingBar A25 features a direct connection to CTP25, enabling a simplified login process. Only need to log in once. This streamlined login experience saves users time and enhances convenience.
Multi-Platform Flexibility
Yealink MeetingBar A25 supports native Teams Rooms, Zoom Rooms, etc. Additionally, it supports BYOD*. In BYOD mode, MeetingBar A25 can serve as video and audio peripherals for your computer in meetings via third-party applications.
Remote Device Management
The Yealink MeetingBar A25 is networked and reports to the device management platform, allowing for remote management, configuration, and upgrades.
Specifications
| |
|---|
| • Android 13
• Based on Microsoft Device Ecosystem Platform (MDEP) |
| • Number of cameras: 3
• Lens FOV
- 1x Ultra-Wide Camera: DFOV 182°, HFOV 151°, VFOV 81°
- 2x Tele Camera: DFOV 93.5°, HFOV 84.4°, VFOV 53.1°
• Maximum pixels: 3 * 4k Cameras, all with 8MP image sensors
• Number of preset positions: 9
• Depth of field: 0.4-2.5 meters
• Maximum resolution: 3840 * 2160
• Maximum frame rate: 30fps
• Video output resolution: 4k (2160p) 30fps, 1080p60fps
• Privacy cover: Electric lens cap
• Electronic gimbal
• Lens calibration
• Intelligence Features
- IntelliFocus (2 portraits)
- Auto Framing
- Speaker Tracking
- Picture in Picture
- Video Fence
- Smart Gallery (Zoom Rooms only) |
| • Built-in a 10W speaker
- Rated power: 10W
- Maximum power: 12W
• Maximum sound pressure level: 90dBSPL 10W@1m
• Frequency response: 100-16kHz
• Sensitivity: 86dB SPL @ 1W @ 0.5 meter
• Sampling rate: 48kHz
• Sound emission angle: Forward-facing
• Total Harmonic Distortion (THD): at 10W, 1kHz, <5%
• Rated impedance: 4 ohms |
| • Built-in 8 MEMS microphone array
• 5-meter pickup distance, 3.5-meter high-quality pickup distance
• Signal-to-noise ratio: 72dB@1kHz
• Maximum sound pressure level: 130dBSPL (whole device), 100dBSPL (individual microphone)
• Dynamic range: 28-100dBSPL
• Sensitivity: -38dBV/pa
• Frequency response: 100-20kHz
• Sampling rate: 48k32bit
• Bit depth: 32-bit
• Audio processing: Full duplex, AEC (Acoustic Echo Cancellation), AGC (Automatic Gain Control)
• Noise suppression: AI-enhanced noise suppression
• Expansion Mics: not supported |
| • Lens Resolution: up to 4k30fps
• Bandwidth requirement: 10Mbps or more |
| • Teams: 1080P30fps in meeting, 4k30fps in local sharing
• Zoom: up to 1080p30fps
• General Mode (BYOM): up to 4k30fps
• RingCentral: 1080p30fps
• H.323/SIP: 1080p30fps |
| • H.264 High profile, H.264 SVC, H.264 |
| • ARES: 24kHz bandwidth
• G.722.1C: 16kHz bandwidth
• G.722.1: 8kHz bandwidth
• G.722: 8kHz bandwidth
• G.711 (PCMA/PCMU): 4kHz bandwidth
• G.729: 8kHz bandwidth |
| • Full Disk Encryption: AES-128, AES-256
• Data Encryption: Symmetric Keys, PKI
• Device Identity: Protected by device attestation
• Device Access: Authenticated using API
• Key Protection: Arm TrustZone, RPMP |
Communication standard protocol | • H.323/SIP in General Mode
• Dual stream protocol: H.239 (H.323) / BFCP (SIP)
• FECC: H.224/H.281
• H.323 protocol suit: H.245, H.225, H.235, H.241
• Gatekeeper account and SIP account |
| • Wi-Fi 6
- 2.4G & 5G dual-band, 802.11a/b/g/n/ac/ax
- 2x2 MIMO
• Bluetooth 5.1
• TCP/IP (IPv4/IPv6), DHCP/static IP
• HTTPS secure web access |
| • Automatic configuration via web page/display/AutoP
• Firmware upgrade, factory reset
• Configuration import and export
• System log export |
| • Yealink Https Web Portal
• Yealink Device Management Platform
• Yealink Management Cloud Service
• Microsoft Device Management Platform(Microsoft Teams Admin Center/Intune)
• Zoom Device Management |
| • Wall mount (provided with the product)
• Use TV Mount (additional: purchase VB-TVMount-01, VB-TVMount-02 or TV-Clip Mount)
• Place on the desktop (additional: purchase VB-TabletopMount-01) |
| • 1x USB2.0 Type-A port
• 1x USB2.0 Type-C port(side)
• 1xUSB3.0 Type-C port
- video input supports formats up to maximum 4k30 fps, including 1080p60fps
• 1x Ethernet port: 10/100/1000Mbps
• 1x Yealink VCH port (RJ-45)
• 1x HDMI-out port
- video output supports formats up to maximum 4k30fps, including 1080p60fps
- supports HDMI CEC
• 1x 3.5mm Line-out port
• 1x Power port
• 1x Security lock slot
• 1x Reset slot |
| • MeetingBar A25
• Power adapter, 3.5m/11.48ft
• 1x HDMI cable, 1.8m/5.91ft
• 1x Network cable, 3m/9.84ft
• 1x USB A to C cable, 3.0m/9.84ft
• Wall Mount
• Cable cover
• MeetingBar A25 quick start guide
• Optional Package
- A25-010: A25+VCR11+USB C to C cable (1.8m/5.91ft)
- A25-031: A25+CTP25 Package (CTP25, 2m/6.56ft 65W PD power adapter, 7.5m/24.6ft Network cable, 1.2m/3.94ft USB C to C cable, High stand, Cable management cover) |
| • Operating humidity: 10 - 95%
• Operating temperature: 0 - 40°C
• Storage temperature: -30?~70?
• BTU/hr: 38 in idle, 58 in meeting |
Dimensions and weight(W × D × H) | • MeetingBar A25: 570x80x65 mm
• N.W/CTN: 3.812kg
• G.W/CTN: 4.290kg |
| • Standard: 2-year limited hardware warranty included
• Extended: Additional extended warranties are available at the time of hardware purchase. Contact your reseller. |
