| Standards |
IEEE 802.3z,
1000Base-SX |
| Connectors |
LC
for 62.5/125µm or 50/125µm cable |
| Dimensions (H
x W x D) |
2.23 x 0.53 x 0.34 in
(56.8 x 13.6 x 8.6 mm) |
| Weight |
0.58 oz (16.3 g) |
| Storage
temperature |
–40–185ºF (–40–85ºC) |
| Case operating temperature |
23–158ºF (–5–70ºC) |
| Operative relative humidity |
85% at 77ºF (25ºC) |
| Operating
distance multi-mode fiber (MMF) |
OM1:
900 ft (275 m) |
| OM2: 900–1,800 ft (275–550 m) |
| OM3: 1,800 ft (550 m) |
| Power
consumption |
1.1W |
| MTBF |
>10 years |
| Safety
certification |
UL 60950-1, CSA-C22.2
No.60950-1 |
| Environmental compliance |
RoHS |
